Create your Unity apps with LLMs!

MCP for Unity acts as a bridge, allowing AI assistants (Claude, Cursor, Antigravity, VS Code, etc) to interact directly with your Unity Editor via a local MCP (Model Context Protocol) Client. Give your LLM tools to manage assets, control scenes, edit scripts, and automate tasks within Unity.

---

💬 Join Our Discord

Get help, share ideas, and collaborate with other MCP for Unity developers!

---

Key Features 🚀

• 🗣️ Natural Language Control: Instruct your LLM to perform Unity tasks.
• 🛠️ Powerful Tools: Manage assets, scenes, materials, scripts, and editor functions.
• 🤖 Automation: Automate repetitive Unity workflows.
• 🧩 Extensible: Designed to work with various MCP Clients.
• 🌐 HTTP-First Transport: Ships with HTTP connections enabled by default (stdio is still available as a fallback).

Tools

Your LLM can use functions like:

• manage_asset: Performs asset operations (import, create, modify, delete, search, etc.).
• manage_editor: Controls editor state (play mode, active tool, tags, layers).
• manage_gameobject: Manages GameObjects (create, modify, delete, find, duplicate, move).
• manage_components: Manages components on GameObjects (add, remove, set properties).
• manage_material: Manages materials (create, set properties, colors, assign to renderers).
• manage_prefabs: Performs prefab operations (open/close stage, save, create from GameObject).
• manage_scene: Manages scenes (load, save, create, get hierarchy, screenshot).
• manage_script: Legacy script operations (create, read, delete). Prefer apply_text_edits or script_apply_edits.
• manage_scriptable_object: Creates and modifies ScriptableObject assets.
• manage_shader: Shader CRUD operations (create, read, modify, delete).
• manage_vfx: VFX effect operations, including line/trail renderer, particle system, and VisualEffectGraph (in development).
• batch_execute: ⚡ RECOMMENDED - Executes multiple commands in one batch for 10-100x better performance. Use this for any repetitive operations.
• find_gameobjects: Search for GameObjects by name, tag, layer, component, path, or ID (paginated).
• find_in_file: Search a C# script with a regex pattern and return matching line numbers and excerpts.
• read_console: Gets messages from or clears the Unity console.
• refresh_unity: Request asset database refresh and optional compilation.
• run_tests: Starts tests asynchronously, returns job_id for polling.
• get_test_job: Polls an async test job for progress and results.
• debug_request_context: Return the current request context details (client_id, session_id, and meta dump).
• execute_custom_tool: Execute project-scoped custom tools registered by Unity.
• execute_menu_item: Executes Unity Editor menu items (e.g., "File/Save Project").
• set_active_instance: Routes tool calls to a specific Unity instance. Requires Name@hash from unity_instances.
• apply_text_edits: Precise text edits with line/column ranges and precondition hashes.
• script_apply_edits: Structured C# method/class edits (insert/replace/delete) with safer boundaries.
• validate_script: Fast validation (basic/standard) to catch syntax/structure issues.
• create_script: Create a new C# script at the given project path.
• delete_script: Delete a C# script by URI or Assets-relative path.
• get_sha: Get SHA256 and metadata for a Unity C# script without returning contents.

Resources

Your LLM can retrieve the following resources:

• custom_tools [mcpforunity://custom-tools]: Lists custom tools available for the active Unity project.
• unity_instances [mcpforunity://instances]: Lists all running Unity Editor instances with details (name, path, hash, status, session).
• menu_items [mcpforunity://menu-items]: All available menu items in the Unity Editor.
• get_tests [mcpforunity://tests]: All available tests (EditMode + PlayMode) in the Unity Editor.
• get_tests_for_mode [mcpforunity://tests/{mode}]: All available tests for a specific mode (EditMode or PlayMode).
• gameobject_api [mcpforunity://scene/gameobject-api]: Documentation for GameObject resources and how to use find_gameobjects tool.
• gameobject [mcpforunity://scene/gameobject/{instance_id}]: Read-only access to GameObject data (name, tag, transform, components, children).
• gameobject_components [mcpforunity://scene/gameobject/{instance_id}/components]: Read-only access to all components on a GameObject with full property serialization.
• gameobject_component [mcpforunity://scene/gameobject/{instance_id}/component/{component_name}]: Read-only access to a specific component's properties.
• editor_active_tool [mcpforunity://editor/active-tool]: Currently active editor tool (Move, Rotate, Scale, etc.) and transform handle settings.
• editor_prefab_stage [mcpforunity://editor/prefab-stage]: Current prefab editing context if a prefab is open in isolation mode.
• editor_selection [mcpforunity://editor/selection]: Detailed information about currently selected objects in the editor.
• editor_state [mcpforunity://editor/state]: Editor readiness snapshot with advice and staleness info.
• editor_windows [mcpforunity://editor/windows]: All currently open editor windows with titles, types, positions, and focus state.
• project_info [mcpforunity://project/info]: Static project information (root path, Unity version, platform).
• project_layers [mcpforunity://project/layers]: All layers defined in TagManager with their indices (0-31).
• project_tags [mcpforunity://project/tags]: All tags defined in TagManager.

---

How It Works

MCP for Unity connects your tools using two components:

1. MCP for Unity Bridge: A Unity package running inside the Editor. (Installed via Package Manager).
2. MCP for Unity Server: A Python server that runs locally (from a terminal window) and speaks HTTP/JSON-RPC to your MCP client. The Unity window launches it for you in HTTP mode by default; stdio is still available if you switch transports.

---

Installation ⚙️

Prerequisites

If you are not installing via the Unity Asset Store, you will need to install the following:

• Python: Version 3.10 or newer. Download Python
• uv (Python toolchain manager):

  # macOS / Linux
  curl -LsSf https://astral.sh/uv/install.sh | sh

  # Windows (PowerShell)
  winget install --id=astral-sh.uv  -e

  # Docs: https://docs.astral.sh/uv/getting-started/installation/


All installations require these:

• Unity Hub & Editor: Version 2021.3 LTS or newer. Download Unity
• An MCP Client: : Claude Desktop | Claude Code | Cursor | Visual Studio Code Copilot | Windsurf | Others work with manual config

[Optional] Roslyn for Advanced Script Validation

For Strict validation level that catches undefined namespaces, types, and methods:

Method 1: NuGet for Unity (Recommended)

1. Install NuGetForUnity
2. Go to Window > NuGet Package Manager
3. Search for Microsoft.CodeAnalysis, select version 4.14.0, and install the package
4. Also install package SQLitePCLRaw.core and SQLitePCLRaw.bundle_e_sqlite3.
5. Go to Player Settings > Scripting Define Symbols
6. Add USE_ROSLYN
7. Restart Unity

Method 2: Manual DLL Installation

1. Download Microsoft.CodeAnalysis.CSharp.dll and dependencies from NuGet
2. Place DLLs in Assets/Plugins/ folder
3. Ensure .NET compatibility settings are correct
4. Add USE_ROSLYN to Scripting Define Symbols
5. Restart Unity

Note: Without Roslyn, script validation falls back to basic structural checks. Roslyn enables full C# compiler diagnostics with precise error reporting.

---

🌟 Step 1: Install the Unity Package

To install via the Unity Asset Store

1. In your browser, navigate to https://assetstore.unity.com/packages/tools/generative-ai/mcp-for-unity-ai-driven-development-329908
2. Click Add to My Assets.
3. In the Unity Editor, go toWindow > Package Manager.
4. Download and import the asset to your project

To install via Git URL

1. Open your Unity project.
2. Go to Window > Package Manager.
3. Click + -> Add package from git URL....
4. Enter:

   https://github.com/CoplayDev/unity-mcp.git?path=/MCPForUnity


5. Click Add.

Need a stable/fixed version? Use a tagged URL instead (updates require uninstalling and re-installing):

https://github.com/CoplayDev/unity-mcp.git?path=/MCPForUnity#v8.6.0

To install via OpenUPM

1. Install the OpenUPM CLI
2. Open a terminal (PowerShell, Terminal, etc.) and navigate to your Unity project directory
3. Run openupm add com.coplaydev.unity-mcp

Note: If you installed the MCP Server before Coplay's maintenance, you will need to uninstall the old package before re-installing the new one.

⚡️ Step 2: Start the Local HTTP Server (Default)

HTTP transport is enabled out of the box. The Unity window can launch the FastMCP server for you:

1. Open Window > MCP for Unity.
2. Make sure the Transport dropdown is set to HTTP Local (default) and the HTTP URL is what you want (defaults to http://localhost:8080).
3. Click Start Server. Unity spawns a new operating-system terminal running uv ... server.py --transport http.
4. Keep that terminal window open while you work; closing it stops the server. Use the Stop Session button in the Unity window if you need to tear it down cleanly.

Prefer stdio? Change the transport dropdown to Stdio and Unity will fall back to the embedded TCP bridge instead of launching the HTTP server.

Manual launch (optional)

You can also start the server yourself from a terminal—useful for CI or when you want to see raw logs:

uvx --from "git+https://github.com/CoplayDev/unity-mcp@v8.6.0#subdirectory=Server" mcp-for-unity --transport http --http-url http://localhost:8080

Keep the process running while clients are connected.

🛠️ Step 3: Configure Your MCP Client

Connect your MCP Client (Claude, Cursor, etc.) to the HTTP server from Step 2 (auto) or via Manual Configuration (below).

For Claude Desktop Users, try using our manually scrapped Unity_Skills by downloading and uploading the claude_skill_unity.zip following this link.

Option A: Configure Buttons (Recommended for Claude/Cursor/VSC Copilot)

1. In Unity, go to Window > MCP for Unity.
2. Select your Client/IDE from the dropdown.
3. Click the Configure Button. (Or the Configure All Detected Clients button will try to configure every client it finds, but takes longer.)
4. Look for a green status indicator 🟢 and "Connected ✓". (This writes the HTTP url pointing at the server you launched in Step 2.)

Client-specific troubleshooting

• VSCode: uses Code/User/mcp.json with top-level servers.unityMCP, "type": "http", and the URL from Step 2. On Windows, MCP for Unity still prefers an absolute uv.exe path when you switch back to stdio.
• Cursor / Windsurf (help link): if uv is missing, the MCP for Unity window shows "uv Not Found" with a quick [HELP] link and a "Choose uv Install Location" button.
• Claude Code (help link): if claude isn't found, the window shows "Claude Not Found" with [HELP] and a "Choose Claude Location" button. Unregister now updates the UI immediately.

Option B: Manual Configuration

If Auto-Setup fails or you use a different client:

1. Find your MCP Client's configuration file. (Check client documentation).
   • Claude Example (macOS): ~/Library/Application Support/Claude/claude_desktop_config.json
   • Claude Example (Windows): %APPDATA%\Claude\claude_desktop_config.json
2. Edit the file to add/update the mcpServers section so it points at the HTTP endpoint from Step 2.

Click for Client-Specific JSON Configuration Snippets...

---

Claude Code

If you're using Claude Code, you can register the MCP server using the below commands:

macOS:

claude mcp add --scope user UnityMCP -- uv --directory /Users/USERNAME/Library/AppSupport/UnityMCP/UnityMcpServer/src run server.py

Windows:

claude mcp add --scope user UnityMCP -- "C:/Users/USERNAME/AppData/Local/Microsoft/WinGet/Links/uv.exe" --directory "C:/Users/USERNAME/AppData/Local/UnityMCP/UnityMcpServer/src" run server.py

VSCode (all OS – HTTP default)

{
  "servers": {
    "unityMCP": {
      "type": "http",
      "url": "http://localhost:8080/mcp"
    }
  }
}

macOS / Windows / Linux (Claude Desktop, Cursor, Claude Code, Windsurf, etc. – HTTP default)

{
  "mcpServers": {
    "unityMCP": {
      "url": "http://localhost:8080/mcp"
    }
  }
}

Set the URL to match whatever you entered in the Unity window (include /mcp).

Stdio configuration examples (legacy / optional)

Switch the Unity transport dropdown to Stdio, then use one of the following command/args blocks.

VSCode (stdio)

{
  "servers": {
    "unityMCP": {
      "type": "stdio",
      "command": "uv",
      "args": [
        "--directory",
        "<ABSOLUTE_PATH_TO>/UnityMcpServer/src",
        "run",
        "server.py",
        "--transport",
        "stdio"
      ]
    }
  }
}

macOS / Linux (stdio)

{
  "mcpServers": {
    "unityMCP": {
      "command": "uv",
      "args": [
        "run",
        "--directory",
        "/Users/YOUR_USERNAME/Library/AppSupport/UnityMCP/UnityMcpServer/src",
        "server.py",
        "--transport",
        "stdio"
      ]
    }
  }
}

Windows (stdio)

{
  "mcpServers": {
    "unityMCP": {
      "command": "C:/Users/YOUR_USERNAME/AppData/Local/Microsoft/WinGet/Links/uv.exe",
      "args": [
        "run",
        "--directory",
        "C:/Users/YOUR_USERNAME/AppData/Local/UnityMCP/UnityMcpServer/src",
        "server.py",
        "--transport",
        "stdio"
      ]
    }
  }
}

Replace YOUR_USERNAME and AppSupport path segments as needed for your platform.

---

Usage ▶️

1. Open your Unity Project and verify the HTTP server is running (Window > MCP for Unity > Start Local HTTP Server). The indicator should show "Session Active" once the server is up.

2. Start your MCP Client (Claude, Cursor, etc.). It connects to the HTTP endpoint configured in Step 3—no extra terminals will be spawned by the client.

3. Interact! Unity tools should now be available in your MCP Client.

   Example Prompt: Create a 3D player controller, Create a tic-tac-toe game in 3D, Create a cool shader and apply to a cube.

💡 Performance Tip: Use batch_execute

When performing multiple operations, use the batch_execute tool instead of calling tools one-by-one. This dramatically reduces latency and token costs (supports up to 25 commands per batch):

❌ Slow: Create 5 cubes → 5 separate manage_gameobject calls
✅ Fast: Create 5 cubes → 1 batch_execute call with 5 commands

❌ Slow: Find objects, then add components to each → N+M separate calls
✅ Fast: Find objects, then add components → 1 find + 1 batch with M component adds

Example prompt: "Create 10 colored cubes in a grid using batch_execute"

Working with Multiple Unity Instances

MCP for Unity supports multiple Unity Editor instances simultaneously. Each instance is isolated per MCP client session.

To direct tool calls to a specific instance:

1. List available instances: Ask your LLM to check the unity_instances resource
2. Set the active instance: Use set_active_instance with the exact Name@hash shown (e.g., MyProject@abc123)
3. All subsequent tools route to that instance until changed. If multiple instances are running and no active instance is set, the server will error and instruct you to select one.

Example:

User: "List all Unity instances"
LLM: [Shows ProjectA@abc123 and ProjectB@def456]

User: "Set active instance to ProjectA@abc123"
LLM: [Calls set_active_instance("ProjectA@abc123")]

User: "Create a red cube"
LLM: [Creates cube in ProjectA]

---

Development & Contributing 🛠️

Development Setup and Guidelines

See README-DEV.md for complete development setup and workflow documentation.

Adding Custom Tools

MCP for Unity uses a Python MCP Server tied with Unity's C# scripts for tools. If you'd like to extend the functionality with your own tools, learn how to do so in CUSTOM_TOOLS.md.

How to Contribute

1. Fork the main repository.
2. Create an issue to discuss your idea or bug.
3. Create a branch (feature/your-idea or bugfix/your-fix).
4. Make changes.
5. Commit (feat: Add cool new feature).
6. Push your branch.
7. Open a Pull Request against the main branch, referencing the issue you created earlier.

---

📊 Telemetry & Privacy

MCP for Unity includes privacy-focused, anonymous telemetry to help us improve the product. We collect usage analytics and performance data, but never your code, project names, or personal information.

• 🔒 Anonymous: Random UUIDs only, no personal data
• 🚫 Easy opt-out: Set DISABLE_TELEMETRY=true environment variable
• 📖 Transparent: See TELEMETRY.md for full details

Your privacy matters to us. All telemetry is optional and designed to respect your workflow.

---

Troubleshooting ❓

Click to view common issues and fixes...

• Unity Bridge Not Running/Connecting:
  • Ensure Unity Editor is open.
  • Check the status window: Window > MCP for Unity.
  • Restart Unity.
• MCP Client Not Connecting / Server Not Starting:
  • Make sure the local HTTP server is running (Window > MCP for Unity > Start Server). Keep the spawned terminal window open.
  • Verify Server Path: Double-check the --directory path in your MCP Client's JSON config. It must exactly match the installation location:
    • Windows: %USERPROFILE%\AppData\Local\UnityMCP\UnityMcpServer\src
    • macOS: ~/Library/AppSupport/UnityMCP/UnityMcpServer\src
    • Linux: ~/.local/share/UnityMCP/UnityMcpServer\src
  • Verify uv: Make sure uv is installed and working (uv --version).
  • Run Manually: Try running the server directly from the terminal to see errors:

    cd /path/to/your/UnityMCP/UnityMcpServer/src
    uv run server.py


• Configuration Failed:
  • Use the Manual Configuration steps. The plugin may lack permissions to write to the MCP client's config file.

Still stuck? Open an Issue or Join the Discord!

---

License 📜

MIT License. See LICENSE file.

---

Star History

Unity AI Tools by Coplay

Coplay offers 2 AI tools for Unity

• MCP for Unity is available freely under the MIT license.
• Coplay is a premium Unity AI assistant that sits within Unity and is more than the MCP for Unity.

(These tools have different tech stacks. See this blog post comparing Coplay to MCP for Unity.)

Disclaimer

This project is a free and open-source tool for the Unity Editor, and is not affiliated with Unity Technologies.
